| Light source | Osram P-VIP 230W Lamp lifespan: 2000h Electronic ballast |
| Optic system | Beam Angle: 3,8° Electronic focus Luminous flux: 41.700 lux @ 20mt |
| Color system | Color wheel with 14 colors + white (2x CTO – CTB) |
| Effects | Fixed gobo wheel with 17 gobos and 6 steps “beam reducer” Gobo shacking effect Gobo scroll effect with adjustable speed 8-facet circular rotating prism with adjustable speed Color rainbow effect Linear dimmer 0-100% Adjustable strobe effect Random strobe effect |
| Control and programming | 1 DMX configuration available: 16 channels Protocol USITT DMX 512 Built-in analyzer for easy fault finding |
| Structure and cabinet | Black metal housing and high resistance plastic materials Color LCD display Pan angle: 540° Tilt angle: 270° Mounting points: 2 pairs of 1/4-turn locks Automatic repositioning of Pan and Tilt after accidental movements XLR 3-poles DMX IN/OUT connection IP rating: IP20 Forced air cooling system with electronic control |
| Power supply | Input Voltage: AC~100-240V, 50/60 Hz Switching power supply unit Max power: 270W @ 230VAC Power input with PowerCON connector Power supply cable 1mt included |
| Weight and dimensions | Net weight: 16,5 kg Dimensions 400x340x620mm |
| Light source | Osram P-VIP 230W Lamp lifespan: 2000h Electronic ballast |
| Optic system | Beam Angle: 3,8° Electronic focus Luminous flux: 41.700 lux @ 20mt |
| Color system | Color wheel with 14 colors + white (2x CTO – CTB) |
| Effects | Fixed gobo wheel with 17 gobos and 6 steps “beam reducer” Gobo shacking effect Gobo scroll effect with adjustable speed 8-facet circular rotating prism with adjustable speed Color rainbow effect Linear dimmer 0-100% Adjustable strobe effect Random strobe effect |
| Control and programming | 1 DMX configuration available: 16 channels Protocol USITT DMX 512 Built-in analyzer for easy fault finding |
| Structure and cabinet | Black metal housing and high resistance plastic materials Color LCD display Pan angle: 540° Tilt angle: 270° Mounting points: 2 pairs of 1/4-turn locks Automatic repositioning of Pan and Tilt after accidental movements XLR 3-poles DMX IN/OUT connection IP rating: IP20 Forced air cooling system with electronic control |
| Power supply | Input Voltage: AC~100-240V, 50/60 Hz Switching power supply unit Max power: 270W @ 230VAC Power input with PowerCON connector Power supply cable 1mt included |
| Weight and dimensions | Net weight: 16,5 kg Dimensions 400x340x620mm |
