| Light source | 12x15W led RGBW Full Color LED lifespan: >50.000h LED refresh frequency: >400Hz flicker free |
| Optic system | Beam angle: 10° x 45° Luminous flux: 1420 lux @5mt |
| Color system | LED source 4 in 1 RGBW Full Color Infinite chromatic possibilities and colour temperature control |
| Effects | Linear Dimmer 0-100% Electronic strobe: 1-20 flashes/s with adjustable speed Color macros selectable by DMX Single pixel control |
| Control and programming | 7 DMX configurations available in: 3/4/5/8/10/48/52 channels Protocol USITT DMX 512 Master / Slave mode Sound mode with adjustable mic sensitivity Static color mode with independent adjustment of strobe Automatic mode with 12 different programs selectable from the display with independent adjustment of the speed and strobe Color mode with 51 different pre-programmed color macros with independent adjustment of the strobe IR remote controller included with possibility to select colors or macros ( Included ) |
| Structure and cabinet | Aluminum housing, black color Color LCD graphic display Mounting points: double adjustable bracket oN the left and right. Single central bracket for suspension “Light up” positioning with angle adjustment 3-poles XLR in/out connection IP rating: IP 20 Forced air fan cooling system with electronic control |
| Power supply | Input Voltage: AC~100-240V 50/60Hz Switching power supply unit Max power: 190W @ 230VAC Power IN/OUT connection with powerCON socket Power supply cable 1,5 mt included Max 4 pcs linkable @240V |
| Weight and dimensions | Net weight: 5,1 kg Dimensions:: 1010x140x160 mm |
| Light source | 12x15W led RGBW Full Color LED lifespan: >50.000h LED refresh frequency: >400Hz flicker free |
| Optic system | Beam angle: 10° x 45° Luminous flux: 1420 lux @5mt |
| Color system | LED source 4 in 1 RGBW Full Color Infinite chromatic possibilities and colour temperature control |
| Effects | Linear Dimmer 0-100% Electronic strobe: 1-20 flashes/s with adjustable speed Color macros selectable by DMX Single pixel control |
| Control and programming | 7 DMX configurations available in: 3/4/5/8/10/48/52 channels Protocol USITT DMX 512 Master / Slave mode Sound mode with adjustable mic sensitivity Static color mode with independent adjustment of strobe Automatic mode with 12 different programs selectable from the display with independent adjustment of the speed and strobe Color mode with 51 different pre-programmed color macros with independent adjustment of the strobe IR remote controller included with possibility to select colors or macros ( Included ) |
| Structure and cabinet | Aluminum housing, black color Color LCD graphic display Mounting points: double adjustable bracket oN the left and right. Single central bracket for suspension “Light up” positioning with angle adjustment 3-poles XLR in/out connection IP rating: IP 20 Forced air fan cooling system with electronic control |
| Power supply | Input Voltage: AC~100-240V 50/60Hz Switching power supply unit Max power: 190W @ 230VAC Power IN/OUT connection with powerCON socket Power supply cable 1,5 mt included Max 4 pcs linkable @240V |
| Weight and dimensions | Net weight: 5,1 kg Dimensions:: 1010x140x160 mm |
