JBar 8 battery
Menu
| Technical data | DMX Wireless Transmitter/Receiver Range: 600 meters (line-of-sight) Number of channels: 512 Operational Frequency: Frequency: 2.402 – 2.480GHz, ISM, 79 channels FHSS: 1100 hops / sec Modulation method: GFSK Maximum Transmit Power: 22dBm Receiver Sensitivity: -93dBm 32-bit ARM Processor, DMA transfer without delay 3-poles XLR In/Out DMX connectors One-touch button with a Tri-color status indicator Groups and dmx protocols easy selection |
| Power supply | Input voltage: 5VDC with USB Type-C connector AC/DC adapter and USB charging cable included Max Power: 500 mA@5V DC max |
| Weight and dimensions | Weight: 230g Dimensions: 103x75x35 mm |
| Technical data | DMX Wireless Transmitter/Receiver Range: 600 meters (line-of-sight) Number of channels: 512 Operational Frequency: Frequency: 2.402 – 2.480GHz, ISM, 79 channels FHSS: 1100 hops / sec Modulation method: GFSK Maximum Transmit Power: 22dBm Receiver Sensitivity: -93dBm 32-bit ARM Processor, DMA transfer without delay 3-poles XLR In/Out DMX connectors One-touch button with a Tri-color status indicator Groups and dmx protocols easy selection |
| Power supply | Input voltage: 5VDC with USB Type-C connector AC/DC adapter and USB charging cable included Max Power: 500 mA@5V DC max |
| Weight and dimensions | Weight: 230g Dimensions: 103x75x35 mm |
