| Technical data | DMX Wireless Receiver Range: 600 meters (line-of-sight) Number of channels: 512 Operational Frequency: Frequency: 2.402 – 2.480GHz, ISM, 79 channels FHSS: 1100 hops / sec Modulation method: GFSK Maximum Transmit Power: 22dBm Receiver Sensitivity: -93dBm 32-bit ARM Processor, DMA transfer without delay 3-poles XLR In connector One-touch button with a Tri-color status indicator Groups and dmx protocols easy selection Integrated antenna |
| Power supply | Input voltage: 5VDC Max Power: 500 mA@5V DC max AC/DC adapter and USB charging cable included Battery type: 1 x lithium-ion 3.7 V, 380 mAh, 1.4 Wh Charge time: 50 min (90%) – 70 min (full) Discharge time: max 20 hrs |
| Weight and dimensions | Weight: 160g Dimensions: 95x18x18 mm |
| Technical data | DMX Wireless Receiver Range: 600 meters (line-of-sight) Number of channels: 512 Operational Frequency: Frequency: 2.402 – 2.480GHz, ISM, 79 channels FHSS: 1100 hops / sec Modulation method: GFSK Maximum Transmit Power: 22dBm Receiver Sensitivity: -93dBm 32-bit ARM Processor, DMA transfer without delay 3-poles XLR In connector One-touch button with a Tri-color status indicator Groups and dmx protocols easy selection Integrated antenna |
| Power supply | Input voltage: 5VDC Max Power: 500 mA@5V DC max AC/DC adapter and USB charging cable included Battery type: 1 x lithium-ion 3.7 V, 380 mAh, 1.4 Wh Charge time: 50 min (90%) – 70 min (full) Discharge time: max 20 hrs |
| Weight and dimensions | Weight: 160g Dimensions: 95x18x18 mm |
